Introducing the BKQF34-D Series 1 Spool Pneumatic Valve, your reliable pneumatic solution for demanding applications. This valve excels in material handling, construction, agriculture, and industrial vehicles.
| Seri BKQF34 Katup Kontrol Pneumatik Parameter | |
|---|---|
| Metode Kontrol | Pneumatik |
| Spul | 1 Spool |
| Kisaran Suhu Sekitar | -40°C hingga +80°C (-40°F hingga +176°F) |
| Tipe Struktur | Katup monoblok |
| Bagian | 1 Bagian |
| Kisaran Viskositas Operasional | 12 - 400 mm²/dt (12 cSt hingga 400 cSt) |
| Aliran Terukur | 40 L/menit (10,5 US gpm) |
| Tekanan Maksimum | Tekanan Dinilai |
| Port Masuk | G1/4 |
| Port Keluar | G1/4 |
| Ukuran Port | G1/4 |
The BKQF34-D Series 1 Spool Pneumatic Valve offers precise pneumatic control with a rated flow of 40 L/min and a maximum pressure of 200 bar. Its monoblock construction ensures durability and reliability, while its operating viscosity range of 12 - 400 mm²/s (12 cSt to 400 cSt) caters to diverse applications. The valve operates flawlessly in temperatures ranging from -40°C to +80°C (-40°F to +176°F). It finds applications in telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders.
