40 cc/rev Hydraulic Gear Pump - High Performance & Reliable

Perpindahan:40 cc/putaran

Tekanan Terukur:20 MPa (2900 psi)

Tekanan Maksimum:25 MPa (3625 psi)

Kecepatan Maksimum:3000 r/min

Putaran:Dua Arah

Merek:BXHS

Tipe Produk:Pompa Roda Gigi Hidrolik

Seri Produk:Seri CBHS-F4 Pompa Roda Gigi Hidrolik

Ukuran kemasan:37*51*19

Kelas kotor:16.00 kg

Ketersediaan: Tersedia

1380 Pandangan Mencari Produk Ini

40 cc/rev Hydraulic Gear Pump - High Performance & Reliable

40 cc/rev Hydraulic Gear Pump - High Performance & Reliable

40 cc/rev Hydraulic Gear Pump - High Performance & Reliable drawing image

Our 40 cc/rev Hydraulic Gear Pump is a high-performance and reliable solution for a wide range of applications, including material handling, construction, agriculture, and industrial vehicles. Available in various displacements, pressure ratings, and configurations, this pump is designed for durability and efficiency.

Seri CBHS-F4 Pompa Roda Gigi Hidrolik Parameter
Perpindahan 40 cc/putaran, 25 cc/putaran, 20 cc/putaran
Tekanan Terukur 20 MPa (2900 psi), 25 MPa (3625 psi)
Tekanan Maksimum 25 MPa (3625 psi)
Kecepatan Terukur 2000 r/min
Kecepatan Maksimum 2500 r/min
Putaran L: Kiri (berlawanan arah jarum jam), R: Kanan ( searah jarum jam)
Bahan Besi Cor, Besi Tuang Aluminium, Aluminium
Struktur Tipe Cam Plate
Versi Flens Flange Oval-A, Flange Persegi-B, Lubang Pemasangan ISO-4, Lubang Pemasangan UNI-3, Flensa SAE
Tipe Poros H: Spline Persegi Panjang, X: Spline Involute, P: Kunci Biasa

This 40 cc/rev Hydraulic Gear Pump is a robust and efficient power source for heavy-duty applications. Featuring a cam plate type design, it delivers high flow rates and pressures for reliable operation. With a range of displacements from 32 cc/rev to 80 cc/rev, rated pressures up to 25 MPa (3625 psi), and maximum speeds up to 2500 r/min, this pump offers flexibility and customization to meet specific requirements. The pump's durable construction ensures long-term performance and reliability in demanding environments. Available with A-Oval or B-Square flanges and a rectangle spline shaft, it can be easily integrated into various systems. Our 40 cc/rev Hydraulic Gear Pump is ideal for applications in telehandlers, forklifts, mini-excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, dumpers, tractors, front-end loaders, and harvesters.
