6 Spool Monoblock Directional Valve | Manufacturer & Global Supplier

Metode Kontrol:Manual dan Joystick

Spul:6 Spool

Aliran Terukur:20 L/menit (5,2 US gpm)

Tekanan Maksimum:315 bar (4600 psi)

Port Masuk:G3/8

Port Keluar:G3/8

Ukuran Port:G3/8

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri DCV20 Katup Arah Monoblok

Ukuran kemasan:32*35*2

Kelas kotor:9.00 kg

Ketersediaan: Tersedia

1629 Pandangan Mencari Produk Ini

6 Spool Monoblock Directional Valve | Manufacturer & Global Supplier

6 Spool Monoblock Directional Valve | Manufacturer & Global Supplier

6 Spool Monoblock Directional Valve | Manufacturer & Global Supplier drawing image

This 6-spool monoblock directional valve is designed for various applications in construction, material handling, agriculture, and industrial vehicles. It offers manual and joystick control options and features a rated flow of 20 L/min and a max pressure of 350 bar.

Seri DCV20 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Elektro-hidraulik, Stik Kontrol, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 20 L/menit (5,2 US gpm)
Tekanan Maksimum 350 bar (5100 psi)
Port Masuk G3/8, M18×1.5, SAE 8, 3/8 NPT
Port Keluar G3/8, M18×1.5, SAE 8, 3/8 NPT
Ukuran Port G3/8, M18×1.5, SAE 8, 3/8 NPT

The Tractor Hydraulic Valve 6 Spool Monoblock Directional Valve is a high-performance, reliable hydraulic control valve specifically designed for heavy-duty applications in various industries. It features a robust monoblock construction with 6 spools, providing precise control of hydraulic functions. The valve is compatible with a wide range of equipment, including telehandlers, forklifts, excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, tractors, front-end loaders, and harvesters. This versatile valve offers both manual and joystick control options, allowing for flexible operation. The DCV20 series valve boasts a rated flow of 20 L/min (5.2 US gpm) and a maximum pressure rating of 350 bar (5100 psi), making it suitable for demanding applications. With an operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and an ambient temperature range of -40°C to +80°C (-40°F to +176°F), this valve ensures reliable operation in a wide range of environments.
