The P80 Series Hydraulic Manual Spool Monoblock Valve is a high-performance, 5-section valve designed for demanding applications in construction, material handling, and industrial vehicles. Offering a flow rate of 80 L/min and a maximum pressure of 250 bar, it provides reliable and efficient hydraulic control for a wide range of machinery.
| Seri P80 Katup Arah Monoblok Parameter | |
|---|---|
| Metode Kontrol | Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Manual dan Joystick |
| Spul | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Kisaran Suhu Sekitar | -40°C hingga +80°C (-40°F hingga +176°F) |
| Tipe Struktur | Katup monoblok |
| Bagian | 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian |
| Kisaran Viskositas Operasional | 15 - 75 mm²/dt (15 cSt hingga 75 cSt) |
| Aliran Terukur | 80 L/menit (21,2 US gpm) |
| Tekanan Maksimum | 315 bar (4600 psi) |
| Port Masuk | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Port Keluar | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Ukuran Port | G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT |
This robust monoblock valve features a solenoid control method, 5 spools, and a rated flow of 80 L/min. It operates within a pressure range of up to 250 bar and a viscosity range of 15 - 75 mm²/s. Designed for use in demanding environments, it boasts an ambient temperature range of -40°C to +80°C. The P80 Series is ideal for applications such as telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi- excavators, mini-excavators, skid steer loaders, and compact wheel loaders. We are seeking global distributors, wholesalers, agents, and traders to partner with us in bringing this high-quality product to a wider market.
