Bespoke Hydraulic Solutions: Customizable P40-G12-G38-3OT Directional Control Valves

Metode Kontrol:Buku Panduan

Spul:3 Spool

Aliran Terukur:40 L/menit (10,5 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G1/2

Port Keluar:G1/2

Ukuran Port:G3/8

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P40 Katup Arah Monoblok

Ukuran kemasan:24*21*13

Kelas kotor:7.00 kg

Ketersediaan: Tersedia

980 Pandangan Mencari Produk Ini

Bespoke Hydraulic Solutions: Customizable P40-G12-G38-3OT Directional Control Valves

Bespoke Hydraulic Solutions: Customizable P40-G12-G38-3OT Directional Control Valves

Bespoke Hydraulic Solutions: Customizable P40-G12-G38-3OT Directional Control Valves drawing image

Introducing our premium Bespoke Hydraulic Solutions: Customizable P40-G12-G38-3OT Directional Control Valves. Engineered with precision, these valves offer exceptional control and versatility for demanding hydraulic applications. With a rated flow of 40 L/min (10.5 US gpm) and a max pressure of 250 bar (3600 psi), they ensure reliable performance in diverse industries.

Seri P40 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Selenoid dan Joystick, Manual dan Joystick, Solenoid dan Kabel
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 40 L/menit (10,5 US gpm)
Tekanan Maksimum 250 bar (3600 psi)
Port Masuk G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port Keluar G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Ukuran Port G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

Our customizable P40-G12-G38-3OT Directional Control Valves feature a robust monoblock valve structure, providing superior durability and leak-proof operation. They operate effortlessly with manual control, making them ideal for precise fluid management. The wide operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) ensures compatibility with various hydraulic fluids. The valves are designed to withstand extreme temperatures from -40°C to +80°C (-40°F to +176°F), ensuring reliable operation in challenging environments.

We offer flexible manufacturing options, including OEM, private label, and custom design services. Our team of experts collaborates closely with customers to develop tailored solutions that meet specific application requirements. Whether you're a distributor, wholesaler, or end-user, we provide comprehensive support throughout the entire process.
