Introducing our Bespoke Hydraulic Solutions: P80-G12-G34-OW Directional Control Valves, meticulously designed and manufactured to meet your unique hydraulic system requirements. These high-performance valves are customizable to fit your specific application, ensuring optimal control and efficiency.
| Seri P80 Katup Arah Monoblok Parameter | |
|---|---|
| Metode Kontrol | Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Manual dan Joystick |
| Spul | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Kisaran Suhu Sekitar | -40°C hingga +80°C (-40°F hingga +176°F) |
| Tipe Struktur | Katup monoblok |
| Bagian | 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian |
| Kisaran Viskositas Operasional | 15 - 75 mm²/dt (15 cSt hingga 75 cSt) |
| Aliran Terukur | 80 L/menit (21,2 US gpm) |
| Tekanan Maksimum | 315 bar (4600 psi) |
| Port Masuk | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Port Keluar | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Ukuran Port | G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT |
**P80 Series Customizable Directional Control Valves**
**Key Features:**
- Manual control for precise operation
- Monoblock valve construction for durability and compactness
- Rated flow of 80 L/min (21.2 US gpm) for efficient hydraulic fluid flow
- Maximum pressure of 250 bar (3600 psi) for demanding applications
- Operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) for versatility
- Ambient temperature range of -40°C to +80°C (-40°F to +176°F) for wide-ranging operation
**Applications:**
- Material Handling: Telehandlers, Forklifts
- Construction and Earth Moving: All Terrain Cranes, Stackers, Motor Graders
- Agriculture: Tractors, Harvesters
- Industrial Vehicles: Aerial Platforms, Skid Steer Loaders
Our P80 Series Directional Control Valves are meticulously engineered to provide exceptional performance and reliability, making them the ideal choice for a wide array of mobile hydraulic applications.
