Introducing the Bespoke Pneumatic Solutions: Customizable DCV100 Directional Control Valves, engineered to meet the unique requirements of your pneumatic systems. With a rated flow of 100 L/min, maximum pressure of 350 bar, and customizable options, these valves offer exceptional performance and flexibility.
| Seri DCV100 Kran Arah Bagian Parameter | |
|---|---|
| Metode Kontrol | Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Kabel, Stik Kontrol, Manual dan Joystick, Manual dan Elektro-hidraulik, Motor listrik, Elektro-hidrolik dan Solenoid |
| Spul | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool, 8 Spool, 9 Spool, 10 Spool, 11 Spool, 12 Spool |
| Kisaran Suhu Sekitar | -40°C hingga +80°C (-40°F hingga +176°F) |
| Tipe Struktur | Katup penampang |
| Bagian | 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian, 8 Bagian, 9 Bagian, 10 Bagian, 11 Bagian, 12 Bagian |
| Kisaran Viskositas Operasional | 15 - 75 mm²/dt (15 cSt hingga 75 cSt) |
| Aliran Terukur | 100 L/menit (26,5 US gpm) |
| Tekanan Maksimum | 315 bar (4600 psi) |
| Port Masuk | G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 3/4 NPT |
| Port Keluar | G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 3/4 NPT |
| Ukuran Port | G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 3/4 NPT |
The DCV100 Series Directional Control Valves feature a compact and modular design, providing a single-section configuration with one spool. They operate efficiently within a wide viscosity range of 15 to 75 mm²/s and an ambient temperature range of -40°C to +60°C. These valves are ideally suited for various applications in Material Handling, Construction and Earth Moving, Agriculture, and Industrial Vehicles, including Telehandlers, Forklifts, All Terrain Cranes, Stackers, Aerial Platforms, Motor Graders, Excavators, Skid Steer Loaders, and Compact Wheel Loaders. At our manufacturing facility, we provide comprehensive services, including OEM manufacturing, private label options, and custom design capabilities. Our commitment to quality and customer satisfaction ensures that you receive tailored solutions that meet your specific requirements.
