High-quality P40 series 4-spool monoblock directional hydraulic valves, rated at 40 L/min and 250 bar, ideal for various applications including material handling, construction, and agriculture. Factory direct supply, offering OEM, private label, and custom solutions. Wholesale pricing available.
| Seri P40 Katup Arah Monoblok Parameter | |
|---|---|
| Metode Kontrol | Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Selenoid dan Joystick, Manual dan Joystick, Solenoid dan Kabel |
| Spul | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Kisaran Suhu Sekitar | -40°C hingga +80°C (-40°F hingga +176°F) |
| Tipe Struktur | Katup monoblok |
| Bagian | 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian |
| Kisaran Viskositas Operasional | 15 - 75 mm²/dt (15 cSt hingga 75 cSt) |
| Aliran Terukur | 40 L/menit (10,5 US gpm) |
| Tekanan Maksimum | 250 bar (3600 psi) |
| Port Masuk | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Port Keluar | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Ukuran Port | G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
Buy high-performance P40-S 4-Spool Monoblock Directional Valves – direct from the factory! We are a leading manufacturer of hydraulic products supplying globally. Our P40 series offers superior performance and reliability. This robust 4-section monoblock valve boasts a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure of 250 bar (3600 psi). Its solenoid control system and wide operating temperature range (-40°C to +80°C) ensure dependable operation in demanding environments.
**Key Features:**
* **Control Method:** Solenoid
* **Sections:** 4 Section
* **Structure Type:** Monoblock valve
* **Rated Flow:** 40 L/min (10.5 US gpm)
* **Max Pressure:** 250 bar (3600 psi)
* **Operating Viscosity:** 15 - 75 mm²/s (15 cSt to 75 cSt)
* **Temperature Range:** -40°C to +80°C (-40°F to +176°F)
* **Application:** MATERIAL HANDLING, CONSTRUCTION & EARTH MOVING, AGRICULTURE, INDUSTRIAL VEHICLES (Forklifts, Telehandlers, Skid Steer Loaders, Compact Wheel Loaders, Mini-Excavators, Tractors, Harvesters, Balers, Sprayers)
**We offer comprehensive solutions, including:**
* **Manufacturing:** High-quality production of hydraulic valves.
* **OEM (Original Equipment Manufacturing):** Customize valves to your specific requirements.
* **Private Labeling:** Brand your own hydraulic valves with your logo and branding.
* **Custom Design:** Tailor-made solutions for unique applications.
* **Wholesale Pricing:** Competitive pricing for large orders.
**We are actively seeking:**
* Distributors
* Wholesalers
* Agents
* Trading Companies
Partner with a reliable hydraulic valve manufacturer offering factory-direct pricing and exceptional service. Contact us today to discuss your needs and explore mutually beneficial collaboration opportunities. Factory direct wholesale pricing available! Contact us for a quote.
