Produksi & Pengiriman
Waktu Produksi 15-30 Hari
1041 Pandangan Mencari Produk Ini
High-quality CBHST1-UNI-63 Hydraulic Gear Pump for global markets. Factory direct supply and support for distributors, wholesalers, agents, and traders. Customize and OEM services available.
| Seri CBHST1-UNI Pompa Roda Gigi Hidrolik Parameter | |
|---|---|
| Perpindahan | 32 cc/putaran, 40 cc/putaran, 50 cc/putaran, 63 cc/putaran, 80 cc/putaran, 100 cc/putaran, 34 cc/putaran, 43 cc/putaran |
| Tekanan Terukur | 23 MPa (3335 psi) |
| Tekanan Maksimum | 25 MPa (3625 psi) |
| Kecepatan Terukur | 2000 r/min |
| Kecepatan Maksimum | 2500 r/min |
| Putaran | Dua Arah |
| Struktur | Pompa Roda Gigi Eksternal |
| Bahan | Besi Cor |
| Tipe Poros | H: Spline Persegi Panjang, X: Spline Involute |
| Versi Flens | Lubang Pemasangan UNI-3 |
CBHST1-UNI-63 Hydraulic Gear Pump with customizable displacement (32 cc/rev to 100 cc/rev), rated pressure (23 MPa), and max speed (2000 r/min to 2500 r/min). Bidirectional rotation, swashplate structure, cast iron material, UNI-3 mounting holes, and options for rectangle spline and involute spline shaft types. Ideal for applications in material handling, construction, agriculture, and industrial vehicles. Trusted by manufacturers of telehandlers, forklifts, and other heavy machinery.
