China Manufacturer for SD6 7 Spool Sectional Directional Control Valve

Metode Kontrol:Manual dan Joystick

Spul:7 Spool

Aliran Terukur:45 L/menit (11,8 US gpm)

Tekanan Maksimum:315 bar (4600 psi)

Port Masuk:G3/8

Port Keluar:G1/2

Ukuran Port:G3/8

Merek:BXHS

Tipe Produk:Kran Arah Bagian

Seri Produk:Seri SD6 Kran Arah Bagian

Ukuran kemasan:37*30*20

Kelas kotor:30.00 kg

Ketersediaan: Tersedia

124 Pandangan Mencari Produk Ini

China Manufacturer for SD6 7 Spool Sectional Directional Control Valve

China Manufacturer for SD6 7 Spool Sectional Directional Control Valve

China Manufacturer for SD6 7 Spool Sectional Directional Control Valve drawing image

As a leading heavy-duty hydraulic manufacturer, we offer the SD6 Series 7-spool sectional directional control valve. Featuring manual and joystick control with a 45 L/min flow rate and 315 bar pressure capacity, this versatile valve is engineered for demanding applications in agriculture, construction, and material handling.

Seri SD6 Kran Arah Bagian Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Hidraulis, Kabel, Stik Kontrol, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool, 8 Spool, 9 Spool, 10 Spool
Kisaran Suhu Sekitar -40°C hingga +60°C (-40°F hingga +140°F)
Tipe Struktur Katup penampang
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian, 8 Bagian, 9 Bagian, 10 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 45 L/menit (11,8 US gpm)
Tekanan Maksimum 315 bar (4600 psi)
Port Masuk G3/8, G1/2
Port Keluar G1/2
Ukuran Port G3/8

Our factory specializes in high-performance hydraulic solutions for the global market, providing professional manufacturing, OEM, and private label services. The SD6 Series 7-spool sectional directional control valve is designed for precision and durability, featuring a rated flow of 45 L/min (11.8 US gpm) and a maximum pressure of 315 bar (4600 psi). With flexible manual and joystick control methods, it is the ideal component for tractors, front-end loaders, mini-excavators, forklifts, and wood splitters. We offer comprehensive customization and wholesale options to meet specific technical requirements. We are actively seeking long-term partnerships with distributors, wholesalers, agents, and traders worldwide. By choosing our factory-direct supply, you benefit from consistent quality, competitive wholesale pricing, and reliable production capacity for all your industrial vehicle and forestry equipment needs.
