Customize P80-G34-5OT Directional Valve to Your Needs

Metode Kontrol:Buku Panduan

Spul:5 Spool

Aliran Terukur:80 L/menit (21,2 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G3/4

Port Keluar:G3/4

Ukuran Port:G3/4

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P80 Katup Arah Monoblok

Ukuran kemasan:26*30*11

Kelas kotor:16.00 kg

Ketersediaan: Tersedia

1053 Pandangan Mencari Produk Ini

Customize P80-G34-5OT Directional Valve to Your Needs

Customize P80-G34-5OT Directional Valve to Your Needs

Customize P80-G34-5OT Directional Valve to Your Needs drawing image

This 5-section, 250 bar rated, 80 L/min directional valve, part of the P80 series, is a high-performance, customizable hydraulic control valve perfect for construction, material handling, and agricultural equipment. It's a monoblock valve designed for demanding applications, offering robust reliability and precise control.

Seri P80 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 80 L/menit (21,2 US gpm)
Tekanan Maksimum 315 bar (4600 psi)
Port Masuk G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port Keluar G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Ukuran Port G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

Our 2 Spool Joystick Hydraulic Control Valve, customizable P80-G34-5OT, is a high-performance directional valve designed to meet your specific needs. It's a 5-section monoblock valve with a rated flow of 80 L/min and a maximum pressure of 250 bar, ideal for a wide range of applications. This manual control valve boasts a compact design and features 5 spools, ensuring smooth and precise control. Its operating viscosity range is 15-75 mm²/s, and it operates flawlessly in ambient temperatures ranging from -40°C to +80°C. Designed for demanding applications, this valve is perfect for construction and earth moving, material handling, agricultural equipment, and industrial vehicles. Its versatility extends to a wide range of applications, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, dumpers, face drill rigs, concrete boom pumps, pave rollers, rotary drilling, and crushers. Customize your valve to fit your specific needs and enhance your equipment's performance.
