The DCV58F Solenoid 1 Spool Sectional Directional Valve is a high-performance hydraulic valve designed for demanding applications in various industries. With a flow rate of 60 L/min, a maximum pressure of 350 bar, and a wide operating temperature range of -40°C to +80°C, this valve ensures reliable and efficient operation even in harsh environments.
| Seri DCV58F Kran Arah Bagian Parameter | |
|---|---|
| Metode Kontrol | Selenoid, Solenoid dan Manual |
| Spul | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool, 8 Spool, 9 Spool, 10 Spool, 11 Spool, 12 Spool |
| Aliran Terukur | 60 L/menit (15,8 US gpm) |
| Tekanan Maksimum | 350 bar (5100 psi) |
| Port Masuk | G1/2, M22×1.5, SAE 10, 1/2 NPT |
| Port Keluar | G1/2, M22×1.5, SAE 10, 1/2 NPT |
| Ukuran Port | G1/2, M22×1.5, SAE 10, 1/2 NPT |
| Bagian | 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian, 8 Bagian, 9 Bagian, 10 Bagian, 11 Bagian, 12 Bagian |
| Tipe Struktur | Katup penampang |
| Kisaran Suhu Sekitar | -40°C hingga +80°C (-40°F hingga +176°F) |
| Kisaran Viskositas Operasional | 15 - 75 mm²/dt (15 cSt hingga 75 cSt) |
**DCV58F Solenoid 1 Spool Sectional Directional Valve**
**Features:**
* Solenoid control for precise and responsive operation
* Sectional design allows for easy integration into complex hydraulic systems
* High flow rate of 60 L/min for efficient fluid flow
* Maximum pressure of 350 bar for demanding applications
* Wide operating viscosity range of 15 - 75 mm²/s
* Robust construction for durability in harsh environments
* Temperature range of -40°C to +80°C for versatility
* Single spool design for simple control
**Applications:**
* Material handling equipment
* Construction machinery
* Agricultural vehicles
* Industrial vehicles
* Telehandlers
* Forklifts
* All-terrain cranes
* Stackers
* Aerial platforms
* Motor graders
* Skid steer loaders
* Compact wheel loaders
* Wheel loaders
* Backhoe loaders
* Dumpers
