Directional Control Valve - P40-G12-G38-2QTW | Wholesale & OEM

Metode Kontrol:Buku Panduan

Spul:2 Spool

Aliran Terukur:40 L/menit (10,5 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G1/2

Port Keluar:G1/2

Ukuran Port:G3/8

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P40 Katup Arah Monoblok

Ukuran kemasan:23*18*13

Kelas kotor:5.10 kg

Ketersediaan: Tersedia

1098 Pandangan Mencari Produk Ini

Directional Control Valve - P40-G12-G38-2QTW | Wholesale & OEM

Directional Control Valve - P40-G12-G38-2QTW | Wholesale & OEM

Directional Control Valve - P40-G12-G38-2QTW | Wholesale & OEM drawing image

The P40-G12-G38-2QTW is a 2-section, monoblock hydraulic directional control valve with a rated flow of 40 L/min and a maximum pressure of 250 bar. It features manual control and is suitable for a wide range of applications in material handling, construction, and agriculture.

Seri P40 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Selenoid dan Joystick, Manual dan Joystick, Solenoid dan Kabel
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 40 L/menit (10,5 US gpm)
Tekanan Maksimum 250 bar (3600 psi)
Port Masuk G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port Keluar G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Ukuran Port G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

This high-performance hydraulic directional control valve from our P40 series is a reliable and efficient solution for various applications. It features a compact design with a 2-section, monoblock structure, delivering smooth and precise control. The valve boasts a rated flow of 40 L/min and a maximum pressure of 250 bar, making it suitable for demanding operations. It also offers a wide operating viscosity range and exceptional temperature resistance. With its manual control mechanism, it provides intuitive and easy operation. This valve is perfect for various applications, including material handling, construction, and agriculture. It is compatible with a range of machinery, such as telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, excavators, skid steer loaders, and compact wheel loaders.
