Exceptional Quality at Factory Prices: P40-2OT Hydraulic Directional Valves. Control Method: Manual and Joystick, Section: 2 Section, Structure Type: Monoblock valve, Rated Flow: 40 L/min (10.5 US gpm), Max Pressure: 250 bar (3600 psi), Operating Viscosity Range: 15 - 75 mm²/s (15 cSt to 75 cSt), Ambient Temperature Range: -40°C to +80°C (-40°F to +176°F), Spool: 2 Spool, Series: P40 Series, Application Area: MATERIAL HANDLING,CONSTRUCTION AND EARTH MOVING,AGRICULTURE,INDUSTRIAL VEHICLES, Applicable Model: TELEHANDLER,FORKLIFT,ALL TERRAIN CRANE,STACKER,AERIAL PLATFORM,MOTOR GRADER,MIDI-EXCAVATOR,MINI-EXCAVATOR,SKID STEER LOADER,COMPACT WHEEL LOADER
| Seri P40 Katup Arah Monoblok Parameter | |
|---|---|
| Metode Kontrol | Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Selenoid dan Joystick, Manual dan Joystick, Solenoid dan Kabel |
| Spul | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Kisaran Suhu Sekitar | -40°C hingga +80°C (-40°F hingga +176°F) |
| Tipe Struktur | Katup monoblok |
| Bagian | 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian |
| Kisaran Viskositas Operasional | 15 - 75 mm²/dt (15 cSt hingga 75 cSt) |
| Aliran Terukur | 40 L/menit (10,5 US gpm) |
| Tekanan Maksimum | 250 bar (3600 psi) |
| Port Masuk | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Port Keluar | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Ukuran Port | G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
The P40-2OT Hydraulic Directional Valves are manufactured by a leading hydraulic products manufacturer and are available at factory prices. These valves are designed for use in a wide range of applications, including material handling, construction and earth moving, agriculture, and industrial vehicles. The valves are available in manual and joystick control methods, and feature a monoblock valve structure, 40 L/min rated flow, 250 bar max pressure, and 2 spool. The valves are also suitable for use in a wide range of ambient temperatures, from -40°C to +80°C (-40°F to +176°F). If you are looking for high-quality hydraulic directional valves at factory prices, the P40-2OT series is an excellent option.
