Factory Direct Valves: P40-U78-U34-2OT-YW Monoblock Directional Control Valves are high-quality valves designed for use in various applications, including material handling, construction, agriculture, and industrial vehicles. These valves feature a manual control method, 3-section monoblock valve structure, 40 L/min (10.5 US gpm) rated flow, 250 bar (3600 psi) max pressure, 15 - 75 mm²/s (15 cSt to 75 cSt) operating viscosity range, -40°C to +80°C (-40°F to +176°F) ambient temperature range, and 3 spool. They are suitable for use in various models, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, backhoe loaders, tractors, and front-end loaders.
| Seri P40 Katup Arah Monoblok Parameter | |
|---|---|
| Metode Kontrol | Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Selenoid dan Joystick, Manual dan Joystick, Solenoid dan Kabel |
| Spul | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Kisaran Suhu Sekitar | -40°C hingga +80°C (-40°F hingga +176°F) |
| Tipe Struktur | Katup monoblok |
| Bagian | 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian |
| Kisaran Viskositas Operasional | 15 - 75 mm²/dt (15 cSt hingga 75 cSt) |
| Aliran Terukur | 40 L/menit (10,5 US gpm) |
| Tekanan Maksimum | 250 bar (3600 psi) |
| Port Masuk | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Port Keluar | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Ukuran Port | G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
**Factory Direct Valves: P40-U78-U34-2OT-YW Monoblock Directional Control Valves**
**Product Overview**
Factory Direct Valves: P40-U78-U34-2OT-YW Monoblock Directional Control Valves are high-quality valves designed for use in various applications, including material handling, construction, agriculture, and industrial vehicles. These valves feature a manual control method, 3-section monoblock valve structure, 40 L/min (10.5 US gpm) rated flow, 250 bar (3600 psi) max pressure, 15 - 75 mm²/s (15 cSt to 75 cSt) operating viscosity range, -40°C to +80°C (-40°F to +176°F) ambient temperature range, and 3 spool. They are suitable for use in various models, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, backhoe loaders, tractors, and front-end loaders.
**Key Features**
* Manual control method
* 3-section monoblock valve structure
* 40 L/min (10.5 US gpm) rated flow
* 250 bar (3600 psi) max pressure
* 15 - 75 mm²/s (15 cSt to 75 cSt) operating viscosity range
* -40°C to +80°C (-40°F to +176°F) ambient temperature range
* 3 spool
* Suitable for use in various models, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, backhoe loaders, tractors, and front-end loaders
