Introducing our premium P40-G12-G38-OW Hydraulic Valves, meticulously engineered and manufactured by our expert team. These valves boast exceptional performance and durability, ensuring optimal operation in demanding hydraulic systems.
| Seri P40 Katup Arah Monoblok Parameter | |
|---|---|
| Metode Kontrol | Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Selenoid dan Joystick, Manual dan Joystick, Solenoid dan Kabel |
| Spul | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Kisaran Suhu Sekitar | -40°C hingga +80°C (-40°F hingga +176°F) |
| Tipe Struktur | Katup monoblok |
| Bagian | 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian |
| Kisaran Viskositas Operasional | 15 - 75 mm²/dt (15 cSt hingga 75 cSt) |
| Aliran Terukur | 40 L/menit (10,5 US gpm) |
| Tekanan Maksimum | 250 bar (3600 psi) |
| Port Masuk | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Port Keluar | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Ukuran Port | G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
**P40-G12-G38-OW Hydraulic Valves: Precision and Power in Every Application**
As a leading manufacturer with a global reach, we proudly present our P40-G12-G38-OW Hydraulic Valves, crafted with the utmost precision and engineered to meet the highest industry standards. These valves are designed to deliver unparalleled performance and durability in a wide range of hydraulic applications, including material handling, construction and earth moving, agriculture, and industrial vehicles.
**Exceptional Features:**
- Manual control for precise operation
- Three-section design for versatility and efficiency
- Monoblock valve construction for enhanced strength and reliability
- Impressive 40 L/min rated flow for maximum productivity
- Maximum pressure of 250 bar to handle demanding applications
- Operating viscosity range of 15 - 75 mm²/s for optimal performance in various fluids
- Wide ambient temperature range of -40°C to +80°C for operation in extreme conditions
- Three-spool design for increased control and functionality
- Part of the renowned P40 Series, known for its exceptional quality and performance
**Extensive Applications:**
- Telehandlers
- Forklifts
- All-terrain cranes
- Stackers
- Aerial platforms
- Motor graders
- Mini-excavators
- Skid steer loaders
- Compact wheel loaders
- Wheel loaders
**Factory Production and Direct Distribution:**
As the manufacturer, we guarantee the highest quality standards and competitive pricing. Our factory production ensures efficient manufacturing processes, while our direct distribution model eliminates intermediaries, offering you the most cost-effective solutions. We are committed to providing exceptional service, prompt delivery, and ongoing support to meet your project requirements.
**Partner with Us:**
We invite distributors, wholesalers, agents, and trade partners to join forces with us and reap the benefits of our superior hydraulic valves. Contact us today to discuss distribution opportunities and explore how our products can enhance your business.
