The High-Performance Hydraulic Gear Pumps are designed to optimize power and efficiency in a wide range of applications. With displacement options ranging from 32 cc/rev to 110 cc/rev and a rated pressure of 23 MPa, these pumps can handle demanding hydraulic systems in industries like construction, agriculture, and industrial vehicles.
| Seri CBHST1-ISO Pompa Roda Gigi Hidrolik Parameter | |
|---|---|
| Perpindahan | 50 cc/putaran, 63 cc/putaran, 80 cc/putaran, 100 cc/putaran, 110 cc/putaran, 34 cc/putaran, 43 cc/putaran, 90 cc/putaran, 120 cc/putaran, 82 cc/putaran |
| Tekanan Terukur | 20 MPa (2900 psi), 23 MPa (3335 psi), 25 MPa (3625 psi) |
| Tekanan Maksimum | 23 MPa (3335 psi), 25 MPa (3625 psi), 28 MPa (4061 psi) |
| Kecepatan Terukur | 2000 r/min |
| Kecepatan Maksimum | 2500 r/min |
| Putaran | Dua Arah |
| Bahan | Besi Cor |
| Struktur | Pompa Roda Gigi Eksternal |
| Versi Flens | Lubang Pemasangan ISO-4 |
| Tipe Poros | H: Spline Persegi Panjang |
The pumps feature a robust cast iron construction and a versatile ISO-4 mounting flange for easy installation. The swashplate structure provides smooth and reliable operation, while the bidirectional rotation allows for flexibility in system design. The H-type rectangle spline shaft ensures compatibility with various hydraulic motors and components. Key applications include telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, mini and midi-excavators, skid steer loaders, and compact wheel loaders.
