High Performance SD8 Manual Sectional Directional Valve

Metode Kontrol:Buku Panduan

Spul:6 Spool

Aliran Terukur:90 L/menit (23,8 US gpm)

Tekanan Maksimum:315 bar (4600 psi)

Port Masuk:G1/2

Port Keluar:G3/4

Ukuran Port:G1/2

Merek:BXHS

Tipe Produk:Kran Arah Bagian

Seri Produk:Seri SD8 Kran Arah Bagian

Ukuran kemasan:40*36*16

Kelas kotor:24.50 kg

Ketersediaan: Tersedia

81 Pandangan Mencari Produk Ini

High Performance SD8 Manual Sectional Directional Valve

High Performance SD8 Manual Sectional Directional Valve

High Performance SD8 Manual Sectional Directional Valve drawing image

The SD8 Series is a high-performance 6-spool manual sectional directional valve designed for versatile hydraulic systems. With a rated flow of 80 L/min and a maximum pressure of 315 bar, it provides precise manual control for a wide range of industrial, agricultural, and construction machinery, ensuring reliable operation in demanding environments.

Seri SD8 Kran Arah Bagian Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Selenoid dan Joystick, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool, 8 Spool, 9 Spool, 10 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup penampang
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian, 8 Bagian, 9 Bagian, 10 Bagian
Kisaran Viskositas Operasional 12 - 400 mm²/dt (12 cSt hingga 400 cSt)
Aliran Terukur 90 L/menit (23,8 US gpm)
Tekanan Maksimum 315 bar (4600 psi)
Port Masuk G1/2, G3/4, SAE 10
Port Keluar G1/2, G3/4, SAE 10, 3/4 NPT
Ukuran Port G1/2, SAE 10

As a leading manufacturer of hydraulic solutions, we offer the SD8 Series Manual Sectional Directional Valve designed for high efficiency and durability. This 6-spool valve features a rated flow of 80 L/min (21.2 US gpm) and supports pressures up to 315 bar (4600 psi), making it suitable for mini-excavators, tractors, forklifts, and wood splitters. We provide comprehensive OEM and ODM services, including private labeling and custom design to meet specific application requirements. Our factory provides direct wholesale pricing and stable supply chains for global markets. We are actively seeking long-term cooperation with distributors, wholesalers, regional agents, and international traders. Whether you need specialized manufacturing or bulk factory supplies, our SD8 series offers the versatility required for material handling, earth moving, and industrial vehicle applications. Contact us for competitive wholesale rates and partnership opportunities.
