High Pressure DCV20 Series 4 Spool Hydraulic Control Valve

Metode Kontrol:Buku Panduan

Spul:4 Spool

Aliran Terukur:20 L/menit (5,2 US gpm)

Tekanan Maksimum:315 bar (4600 psi)

Port Masuk:G3/8

Port Keluar:G3/8

Ukuran Port:G3/8

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri DCV20 Katup Arah Monoblok

Ukuran kemasan:23*21*11

Kelas kotor:6.20 kg

Ketersediaan: Tersedia

107 Pandangan Mencari Produk Ini

High Pressure DCV20 Series 4 Spool Hydraulic Control Valve

High Pressure DCV20 Series 4 Spool Hydraulic Control Valve

High Pressure DCV20 Series 4 Spool Hydraulic Control Valve drawing image

The DCV20 Series is a high-pressure 4-spool manual hydraulic directional control valve designed for compact applications, offering a rated flow of 20 L/min and operating capability up to 350 bar. It is ideal for material handling, agriculture, and construction machinery requiring precise manual control.

Seri DCV20 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Elektro-hidraulik, Stik Kontrol, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 20 L/menit (5,2 US gpm)
Tekanan Maksimum 350 bar (5100 psi)
Port Masuk G3/8, M18×1.5, SAE 8, 3/8 NPT
Port Keluar G3/8, M18×1.5, SAE 8, 3/8 NPT
Ukuran Port G3/8, M18×1.5, SAE 8, 3/8 NPT

As a leading large-scale manufacturer of hydraulic components, we proudly present the DCV20 Series 4 Spool Hydraulic Control Valve. Engineered for high-pressure environments (up to 5100 psi), this manual valve provides exceptional reliability and responsive control for equipment such as forklifts, mini-excavators, and tractors. Our factory offers comprehensive manufacturing services including OEM, private labeling (ODM), and custom design to meet specific technical requirements. We specialize in factory-wholesale supplies, ensuring competitive pricing and consistent quality for the global market. We are actively seeking long-term cooperation with distributors, wholesalers, regional agents, and international traders. Whether you need bulk wholesale orders or customized hydraulic solutions for wood splitters, sweepers, or aerial platforms, our factory production lines are equipped to support your business growth with robust logistics and technical support.
