The P40 Monoblock Directional Valve is a high-performance, heavy-duty valve designed for use in a wide range of applications including material handling, construction, agriculture, and industrial vehicles. Featuring solenoid and joystick control, 3 sections, and a rated flow of 40 L/min, this valve is built for demanding environments.
| Seri P40 Katup Arah Monoblok Parameter | |
|---|---|
| Metode Kontrol | Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Selenoid dan Joystick, Manual dan Joystick, Solenoid dan Kabel |
| Spul | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Kisaran Suhu Sekitar | -40°C hingga +80°C (-40°F hingga +176°F) |
| Tipe Struktur | Katup monoblok |
| Bagian | 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian |
| Kisaran Viskositas Operasional | 15 - 75 mm²/dt (15 cSt hingga 75 cSt) |
| Aliran Terukur | 40 L/menit (10,5 US gpm) |
| Tekanan Maksimum | 250 bar (3600 psi) |
| Port Masuk | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Port Keluar | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Ukuran Port | G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
The P40 Series Monoblock Directional Valve is a high-quality, robust valve designed for heavy-duty applications in various industries such as material handling, construction, agriculture, and industrial vehicles. This valve features a 3-section monoblock structure with a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure of 250 bar (3600 psi). It can handle a wide operating viscosity range of 15-75 mm²/s (15 cSt to 75 cSt) and operates effectively in ambient temperatures ranging from -40°C to +80°C (-40°F to +176°F). Equipped with both solenoid and joystick control, the P40 valve offers versatile control options. With its 3 spools and robust design, this valve is well-suited for demanding applications like telehandlers, forklifts, mini- excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, dumpers, tractors, and harvesters. This valve is available for bulk orders and can be customized to meet specific requirements.
