HSDVG32 Control Valve Customization: OEM and ODM Services Available

Metode Kontrol:Proporsional listrik dan Manual

Spul:4 Spool

Aliran Terukur:140 L/menit (37 US gpm)

Tekanan Maksimum:350 bar (5100 psi)

Port Masuk:G3/4

Port Keluar:G3/4

Ukuran Port:G1/2

Merek:BXHS

Tipe Produk:Katup Kontrol Proporsional

Seri Produk:Seri HSDVG32 Katup Kontrol Proporsional

Packagingsize:34*34*20

Grossweight:46.00 kg

Ketersediaan: Tersedia

1352 Pandangan Mencari Produk Ini

HSDVG32 Control Valve Customization: OEM and ODM Services Available

HSDVG32 Control Valve Customization: OEM and ODM Services Available

HSDVG32 Control Valve Customization: OEM and ODM Services Available drawing image

The HSDVG32 Electro Hydraulic Actuator is a high-performance control valve designed for a wide range of applications. It offers a robust design, high flow rate, and precise control, making it ideal for material handling, construction, agriculture, and industrial vehicles. We offer OEM and ODM services, allowing you to customize the actuator to meet your specific needs.

Seri HSDVG32 Katup Kontrol Proporsional Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-hidraulik, Selenoid, Hidraulik dan Manual, Kabel, Proporsional listrik, Solenoid dan Manual, Proporsional listrik dan Manual
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool, 8 Spool, 9 Spool, 10 Spool, 11 Spool, 12 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup penampang
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian, 8 Bagian, 9 Bagian, 10 Bagian, 11 Bagian, 12 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 140 L/menit (37 US gpm)
Tekanan Maksimum 315 bar (4600 psi)
Port Masuk G3/4
Port Keluar G3/4
Ukuran Port G1/2, G3/4

The HSDVG32 Electro Hydraulic Actuator is a 4-section, sectional valve with a rated flow of 140 L/min and a maximum pressure of 315 bar. It features both electric proportional and manual control methods, allowing for precise and flexible operation. The valve is designed for demanding applications, with an operating viscosity range of 15 - 75 mm²/s and an ambient temperature range of -40°C to +80°C. The HSDVG32 series is compatible with various machines, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, and skid steer loaders. We offer comprehensive OEM and ODM services, enabling you to customize the actuator to your specific requirements. Whether you need a standard model or a highly customized solution, we can tailor the product to meet your exact specifications. Our flexible manufacturing capabilities allow us to provide a wide range of options, including manufacturing, contract manufacturing, private labeling, and wholesale. We are actively seeking distributors, wholesalers, agents, and traders to expand our global reach and bring our high-quality products to a wider audience.
