Hydraulic Directional Valve Experts: Partner with Us for Excellence

Metode Kontrol:Buku Panduan

Spul:7 Spool

Aliran Terukur:40 L/menit (10,5 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G1/2

Port Keluar:G1/2

Ukuran Port:G1/2

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P40 Katup Arah Monoblok

Ukuran kemasan:36*23*13

Kelas kotor:13.50 kg

Ketersediaan: Tersedia

995 Pandangan Mencari Produk Ini

Hydraulic Directional Valve Experts: Partner with Us for Excellence

Hydraulic Directional Valve Experts: Partner with Us for Excellence

Hydraulic Directional Valve Experts: Partner with Us for Excellence drawing image

Our P40 Series 7-section hydraulic multi-way valve is a robust and versatile solution for various applications in material handling, construction, and agriculture. This monoblock valve features a rated flow of 40 L/min, a maximum pressure of 250 bar, and a manual control method. Its reliable performance and wide operating range make it ideal for telehandlers, forklifts, all-terrain cranes, and other heavy-duty equipment.

Seri P40 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Selenoid dan Joystick, Manual dan Joystick, Solenoid dan Kabel
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 40 L/menit (10,5 US gpm)
Tekanan Maksimum 250 bar (3600 psi)
Port Masuk G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port Keluar G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Ukuran Port G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40 Series 7-section hydraulic multi-way valve is a high-performance valve designed for demanding applications. With its 7 spool configuration, it offers precise control of hydraulic fluid flow in various directions. The valve's monoblock structure ensures high strength and durability, while its rated flow of 40 L/min provides efficient operation. The maximum pressure rating of 250 bar guarantees reliable performance even under extreme conditions. This manual control valve is suitable for various applications, including material handling, construction, and agriculture, and is compatible with telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, and motor graders. The valve's wide operating temperature range of -40°C to +80°C ensures reliable operation in diverse environments.
