Hydraulic Directional Valve P80-G12-G34-OW | Manufacturer & Distributor

Metode Kontrol:Buku Panduan

Spul:2 Spool

Aliran Terukur:80 L/menit (21,2 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G1/2

Port Keluar:G3/4

Ukuran Port:G1/2

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P80 Katup Arah Monoblok

Ukuran kemasan:26*18*11

Kelas kotor:8.00 kg

Ketersediaan: Tersedia

1057 Pandangan Mencari Produk Ini

Hydraulic Directional Valve P80-G12-G34-OW | Manufacturer & Distributor

Hydraulic Directional Valve P80-G12-G34-OW | Manufacturer & Distributor

Hydraulic Directional Valve P80-G12-G34-OW | Manufacturer & Distributor drawing image

The P80-G12-G34-OW is a high-performance hydraulic directional valve designed for demanding applications in construction, material handling, agriculture, and industrial vehicles. This manual control, 2-section monoblock valve offers a rated flow of 80 L/min and a maximum pressure of 250 bar, making it ideal for a wide range of mobile equipment.

Seri P80 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 80 L/menit (21,2 US gpm)
Tekanan Maksimum 315 bar (4600 psi)
Port Masuk G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port Keluar G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Ukuran Port G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The P80-G12-G34-OW is a reliable and durable hydraulic directional valve featuring a robust monoblock construction and a 2-spool design. It offers a rated flow of 80 L/min and a maximum pressure of 250 bar, ensuring efficient operation in demanding environments. The valve is suitable for various applications, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, and skid steer loaders. The P80-G12-G34-OW is a manual control valve, allowing for precise and intuitive operation. With a wide operating viscosity range (15-75 mm²/s) and an ambient temperature range of -40°C to +80°C, this valve is designed to withstand diverse operating conditions. Its compact size and lightweight design make it easy to install and integrate into various hydraulic systems.
