Hydraulic Product Manufacturer: P120-G1 Monoblock Valve

Metode Kontrol:Buku Panduan

Spul:1 Spool

Aliran Terukur:120 L/min (31,7 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G1

Port Keluar:G1

Ukuran Port:G1

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P120 Katup Arah Monoblok

Ukuran kemasan:19*35*16

Kelas kotor:13.60 kg

Ketersediaan: Tersedia

984 Pandangan Mencari Produk Ini

Hydraulic Product Manufacturer: P120-G1 Monoblock Valve

Hydraulic Product Manufacturer: P120-G1 Monoblock Valve

Hydraulic Product Manufacturer: P120-G1 Monoblock Valve drawing image

The P120-G1 Monoblock Valve is a high-performance, adjustable hydraulic flow divider valve designed for a wide range of applications in material handling, construction, agriculture, and industrial vehicles. This manual control valve features a compact, robust design with a rated flow of 120 L/min (31.7 US gpm) and a maximum pressure of 250 bar (3600 psi).

Seri P120 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Kabel, Stik Kontrol, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool
Aliran Terukur 120 L/min (31,7 US gpm)
Tekanan Maksimum 250 bar (3600 psi)
Port Masuk G3/4, G1, M27×2.0, SAE 14, SAE 16, 3/4 NPT, 1 NPT, M36×2
Port Keluar G1, SAE 16, 1 NPT, M36×2
Ukuran Port G3/4, G1, M27×2.0, SAE 14, SAE 16, 1 NPT, M36×2
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian
Tipe Struktur Katup monoblok
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)

The P120-G1 Monoblock Valve is a reliable and efficient solution for controlling hydraulic flow in demanding applications. Its robust monoblock construction ensures durability and long service life. This adjustable flow divider valve allows for precise control of hydraulic fluid flow, enabling optimized performance in various equipment such as telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, excavators, skid steer loaders, and compact wheel loaders. The valve operates at a flow rate of 120 L/min (31.7 US gpm) and a maximum pressure of 250 bar (3600 psi), making it suitable for high-demand applications. The manual control method provides simple and direct operation. The P120-G1 Monoblock Valve is a versatile and reliable solution for a wide range of applications in the construction, agriculture, and industrial vehicle sectors.
