Industrial Grade SD5-PG2 Solenoid 6 Spool Monoblock Directional Valve

Metode Kontrol:Selenoid

Spul:6 Spool

Aliran Terukur:45 L/menit (11,8 US gpm)

Tekanan Maksimum:315 bar (4600 psi)

Port Masuk:G1/2

Port Keluar:G1/2

Ukuran Port:G3/8

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri SD5 Katup Arah Monoblok

Ukuran kemasan:31*29*10

Kelas kotor:14.00 kg

Ketersediaan: Tersedia

94 Pandangan Mencari Produk Ini

Industrial Grade SD5-PG2 Solenoid 6 Spool Monoblock Directional Valve

Industrial Grade SD5-PG2 Solenoid 6 Spool Monoblock Directional Valve

Industrial Grade SD5-PG2 Solenoid 6 Spool Monoblock Directional Valve drawing image

The SD5-PG2 is a robust 6-spool monoblock solenoid directional valve designed for demanding industrial, agricultural, and construction applications. Rated for flow up to 45 L/min and pressures up to 315 bar, this high-performance valve ensures precise control across a wide range of mobile equipment.

Seri SD5 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +60°C (-40°F hingga +140°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 40 L/menit (10,5 US gpm)
Tekanan Maksimum 305 bar (4400 psi)
Port Masuk G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8, G1-1/2
Port Keluar G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8
Ukuran Port G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8

As a leading manufacturer of professional hydraulic solutions, we offer the SD5-PG2 solenoid directional valve to global markets. This unit is engineered for durability, supporting heavy-duty operations in applications like forklifts, front-end loaders, mini-excavators, and telehandlers. We are a direct factory source providing flexible manufacturing, OEM, ODM, and customized production services to meet your specific technical requirements. We are actively seeking partnerships with international distributors, wholesalers, and trade companies to expand our global supply chain. Benefit from our factory-direct wholesale pricing, rigorous quality control, and scalable production capacity. Contact us today to discuss how our hydraulic control valves can integrate into your equipment or explore our comprehensive wholesale and private labeling opportunities.
