Industrial Grade SD8 Manual Sectional Hydraulic Valve

Metode Kontrol:Buku Panduan

Spul:6 Spool

Aliran Terukur:90 L/menit (23,8 US gpm)

Tekanan Maksimum:315 bar (4600 psi)

Port Masuk:G1/2

Port Keluar:G3/4

Ukuran Port:G1/2

Merek:BXHS

Tipe Produk:Kran Arah Bagian

Seri Produk:Seri SD8 Kran Arah Bagian

Packagingsize:40*36*16

Grossweight:24.50 kg

Ketersediaan: Tersedia

75 Pandangan Mencari Produk Ini

Industrial Grade SD8 Manual Sectional Hydraulic Valve

Industrial Grade SD8 Manual Sectional Hydraulic Valve

Industrial Grade SD8 Manual Sectional Hydraulic Valve drawing image

The Industrial Grade SD8 Manual Sectional Hydraulic Valve is a high-performance 6-spool control solution designed for heavy-duty mobile and industrial applications. Featuring a rated flow of 80 L/min and capable of handling pressures up to 315 bar, this versatile valve provides precise manual control for diverse machinery including excavators, tractors, and forklifts.

Seri SD8 Kran Arah Bagian Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Selenoid dan Joystick, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool, 8 Spool, 9 Spool, 10 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup penampang
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian, 8 Bagian, 9 Bagian, 10 Bagian
Kisaran Viskositas Operasional 12 - 400 mm²/dt (12 cSt hingga 400 cSt)
Aliran Terukur 90 L/menit (23,8 US gpm)
Tekanan Maksimum 315 bar (4600 psi)
Port Masuk G1/2, G3/4, SAE 10
Port Keluar G1/2, G3/4, SAE 10, 3/4 NPT
Ukuran Port G1/2, SAE 10

As a leading manufacturer of hydraulic solutions, we offer the SD8 Series Manual Sectional Hydraulic Valve, engineered for demanding environments in construction, agriculture, and material handling. This 6-spool valve supports a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 315 bar (4600 psi), ensuring reliable operation for equipment like mini-excavators, skid steer loaders, and wood splitters. We provide comprehensive manufacturing services including OEM, private labeling, and custom configuration to meet specific technical requirements. Our factory specializes in high-volume wholesale supply and is actively seeking global partners, including distributors, wholesalers, agents, and professional traders. By partnering with us, you gain direct factory access to premium hydraulic components with G1/2 inlet and G3/4 outlet ports, optimized for tractors, backhoes, and industrial vehicles. We are committed to supporting your business growth through stable supply chains, competitive wholesale pricing, and flexible manufacturing capabilities.
