Produksi & Pengiriman
Waktu Produksi 15-30 Hari
1156 Pandangan Mencari Produk Ini
The P80-U116-U78-OT 5 Spool Monoblock Directional Valve is a high-performance hydraulic valve designed for use in a wide range of industrial applications. With its manual control, 5 sections, and monoblock construction, this valve offers precise and reliable flow control. Its rated flow of 80 L/min and maximum pressure of 250 bar make it suitable for demanding hydraulic systems. The valve is designed to operate within a viscosity range of 15 - 75 mm²/s and an ambient temperature range of -40°C to +80°C.
| Seri P80 Katup Arah Monoblok Parameter | |
|---|---|
| Metode Kontrol | Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Manual dan Joystick |
| Spul | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Kisaran Suhu Sekitar | -40°C hingga +80°C (-40°F hingga +176°F) |
| Tipe Struktur | Katup monoblok |
| Bagian | 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian |
| Kisaran Viskositas Operasional | 15 - 75 mm²/dt (15 cSt hingga 75 cSt) |
| Aliran Terukur | 80 L/menit (21,2 US gpm) |
| Tekanan Maksimum | 315 bar (4600 psi) |
| Port Masuk | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Port Keluar | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Ukuran Port | G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT |
The P80-U116-U78-OT 5 Spool Monoblock Directional Valve is manufactured to the highest quality standards and is backed by a comprehensive warranty. Its robust construction and durable materials ensure long-lasting performance even in the most challenging operating conditions. The valve is easy to install and maintain, making it an ideal choice for a variety of industrial applications. Its compact size and lightweight design make it easy to integrate into existing systems, while its modular design allows for easy customization to meet specific application requirements.
