The DCV60 series is a robust electro-hydraulic sectional valve designed for precise flow control in demanding mobile and industrial applications. With a 60 L/min rated flow and 350 bar pressure capacity, this valve offers reliable performance for construction, agriculture, and material handling machinery.
| Seri DCV60 Kran Arah Bagian Parameter | |
|---|---|
| Metode Kontrol | Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Solenoid dan Manual, Selenoid dan Joystick, Manual dan Joystick, Motor listrik |
| Spul | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool, 8 Spool, 9 Spool, 10 Spool, 11 Spool, 12 Spool |
| Kisaran Suhu Sekitar | -40°C hingga +80°C (-40°F hingga +176°F) |
| Tipe Struktur | Katup penampang |
| Bagian | 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian, 8 Bagian, 9 Bagian, 10 Bagian, 11 Bagian, 12 Bagian |
| Kisaran Viskositas Operasional | 15 - 75 mm²/dt (15 cSt hingga 75 cSt) |
| Aliran Terukur | 60 L/menit (15,8 US gpm) |
| Tekanan Maksimum | 315 bar (4600 psi), 350 bar (5100 psi) |
| Port Masuk | G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Port Keluar | G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Ukuran Port | G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
As a prominent large-scale manufacturer, we specialize in high-quality DCV60 Electro-hydraulic Sectional Valves engineered for heavy-duty performance in equipment like forklifts, tractors, mini-excavators, and skid steer loaders. We offer comprehensive factory-direct solutions including manufacturing, OEM, private labeling, and custom engineering to meet specific technical requirements. Our facility is equipped to handle large-scale wholesale orders with consistent quality assurance. We are actively seeking long-term partnerships with global distributors, wholesalers, trade agents, and industry-specific dealers. By working directly with us, you benefit from competitive factory-direct pricing, scalable production capacity, and reliable supply chain support. Whether you require standard modular configurations or tailored solutions for unique machinery builds, our engineering team is ready to support your business goals through professional manufacturing and personalized ODM/OEM services.
