Manual Monoblock Directional Valve - P120 Series | Wholesale & OEM

Metode Kontrol:Buku Panduan

Spul:2 Spool

Aliran Terukur:120 L/min (31,7 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G1

Port Keluar:G1

Ukuran Port:G1

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P120 Katup Arah Monoblok

Ukuran kemasan:30*39*17

Kelas kotor:19.00 kg

Ketersediaan: Tersedia

1491 Pandangan Mencari Produk Ini

Manual Monoblock Directional Valve - P120 Series | Wholesale & OEM

Manual Monoblock Directional Valve - P120 Series | Wholesale & OEM

Manual Monoblock Directional Valve - P120 Series | Wholesale & OEM drawing image

The P120 Series 12v Electric Hydraulic Valve is a manual monoblock directional valve designed for a wide range of applications, including construction, agriculture, and material handling. This 2-section valve features a rated flow of 120 L/min and a maximum pressure of 250 bar, making it ideal for use in telehandlers, forklifts, excavators, and other heavy-duty equipment.

Seri P120 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Kabel, Stik Kontrol, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool
Aliran Terukur 120 L/min (31,7 US gpm)
Tekanan Maksimum 250 bar (3600 psi)
Port Masuk G3/4, G1, M27×2.0, SAE 14, SAE 16, 3/4 NPT, 1 NPT, M36×2
Port Keluar G1, SAE 16, 1 NPT, M36×2
Ukuran Port G3/4, G1, M27×2.0, SAE 14, SAE 16, 1 NPT, M36×2
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian
Tipe Struktur Katup monoblok
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)

This 12v Electric Hydraulic Valve from the P120 series is a reliable and durable solution for your hydraulic system needs. With a manual control method, 2 sections, and a monoblock structure, this valve offers precise control over hydraulic fluid flow. Featuring a rated flow of 120 L/min and a maximum pressure of 250 bar, the valve is well-suited for a variety of applications, including material handling, construction, and agriculture. Its robust design ensures long-term performance even in demanding environments. Available for wholesale and OEM orders, this valve can be customized to meet your specific requirements. Its versatility makes it an ideal choice for various heavy-duty equipment, such as telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders.
