Manual Monoblock Directional Valve - P40-G38-OT Series | Wholesale & OEM

Metode Kontrol:Buku Panduan

Spul:1 Spool

Aliran Terukur:40 L/menit (10,5 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G3/8

Port Keluar:G3/8

Ukuran Port:G3/8

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P40 Katup Arah Monoblok

Ukuran kemasan:23*16*11

Kelas kotor:3.00 kg

Ketersediaan: Tersedia

1013 Pandangan Mencari Produk Ini

Manual Monoblock Directional Valve - P40-G38-OT Series | Wholesale & OEM

Manual Monoblock Directional Valve - P40-G38-OT Series | Wholesale & OEM

Manual Monoblock Directional Valve - P40-G38-OT Series | Wholesale & OEM drawing image

The P40-G38-OT Series Manual Monoblock Directional Valve is a high-performance hydraulic valve designed for various applications including wood splitting, material handling, construction, and agriculture. It features a compact monoblock construction, manual control, and a rated flow of 40 L/min, making it ideal for a wide range of hydraulic systems.

Seri P40 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Selenoid dan Joystick, Manual dan Joystick, Solenoid dan Kabel
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 40 L/menit (10,5 US gpm)
Tekanan Maksimum 250 bar (3600 psi)
Port Masuk G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port Keluar G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Ukuran Port G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40-G38-OT Series Manual Monoblock Directional Valve is a robust and reliable hydraulic component designed for demanding applications. This 1-section valve features a compact monoblock construction, ensuring durability and ease of installation. The manual control method allows for precise and convenient operation. With a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure of 250 bar (3600 psi), this valve is suitable for a wide range of hydraulic systems. Its operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and ambient temperature range of -40°C to +80°C (-40°F to +176°F) ensure optimal performance in various environmental conditions. The P40-G38-OT Series valve is specifically designed for applications such as material handling, construction, and agriculture, making it suitable for use in telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, excavators, skid steer loaders, and backhoe loaders.
