Manual Monoblock Directional Valve - P80-G34 Series | Wholesale & OEM

Metode Kontrol:Buku Panduan

Spul:6 Spool

Aliran Terukur:80 L/menit (21,2 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G3/4

Port Keluar:G3/4

Ukuran Port:G3/4

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P80 Katup Arah Monoblok

Ukuran kemasan:26*36*11

Kelas kotor:18.60 kg

Ketersediaan: Tersedia

1136 Pandangan Mencari Produk Ini

Manual Monoblock Directional Valve - P80-G34 Series | Wholesale & OEM

Manual Monoblock Directional Valve - P80-G34 Series | Wholesale & OEM

Manual Monoblock Directional Valve - P80-G34 Series | Wholesale & OEM drawing image

The P80-G34 Series Double Hydraulic Valve Manual Monoblock Directional Valve is a high-performance, reliable valve designed for a wide range of applications in material handling, construction, agriculture, and industrial vehicles. This 6-section monoblock valve offers a rated flow of 80 L/min and a maximum pressure of 250 bar, making it suitable for demanding operating conditions. It's available for wholesale and OEM orders.

Seri P80 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 80 L/menit (21,2 US gpm)
Tekanan Maksimum 315 bar (4600 psi)
Port Masuk G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port Keluar G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Ukuran Port G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The P80-G34 Series Double Hydraulic Valve Manual Monoblock Directional Valve is a robust and versatile solution for controlling hydraulic systems in various applications. It features a manual control method with 6 sections and a monoblock valve structure, ensuring reliable and precise operation. With a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 250 bar (3600 psi), this valve is suitable for demanding applications. It operates within a viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and withstands ambient temperatures from -40°C to +80°C (-40°F to +176°F). The valve is specifically designed for use in a variety of machinery, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi- excavators, mini-excavators, skid steer loaders, and compact wheel loaders. Available for wholesale and OEM orders, this valve is a reliable and efficient solution for your hydraulic system needs.
