Manual Monoblock Directional Valve - P80 Series | Wholesale & OEM

Metode Kontrol:Selenoid

Spul:2 Spool

Aliran Terukur:80 L/menit (21,2 US gpm)

Tekanan Maksimum:200 bar (2900 psi)

Port Masuk:G3/4

Port Keluar:G3/4

Ukuran Port:G1/2

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P80 Katup Arah Monoblok

Ukuran kemasan:37*18*11

Kelas kotor:9.50 kg

Ketersediaan: Tersedia

1106 Pandangan Mencari Produk Ini

Manual Monoblock Directional Valve - P80 Series | Wholesale & OEM

Manual Monoblock Directional Valve - P80 Series | Wholesale & OEM

Manual Monoblock Directional Valve - P80 Series | Wholesale & OEM drawing image

The P80 Series 3 Way Manual Monoblock Directional Valve is a high-performance hydraulic valve designed for use in a variety of applications, including material handling, construction, agriculture, and industrial vehicles. This valve features a 2-section, 2-spool design with a rated flow of 80 L/min and a maximum pressure of 250 bar. It is available for OEM and wholesale orders.

Seri P80 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 80 L/menit (21,2 US gpm)
Tekanan Maksimum 315 bar (4600 psi)
Port Masuk G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port Keluar G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Ukuran Port G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

This 3 Way Manual Monoblock Directional Valve from the P80 Series is a reliable and efficient solution for controlling hydraulic systems in various applications. Its compact design and robust construction make it suitable for demanding environments. The valve features a solenoid control method, a 2-section monoblock structure, and a rated flow of 80 L/min. It can withstand a maximum pressure of 250 bar and operates within a viscosity range of 15 - 75 mm²/s. The valve is designed for use in a wide range of temperatures, from -40°C to +80°C. Its versatility and performance make it ideal for various applications, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, and compact wheel loaders. We offer this valve for wholesale and OEM orders, catering to the specific needs of our customers. If you are looking for a high-quality, reliable, and efficient 3 Way Manual Monoblock Directional Valve, the P80 Series is the perfect choice.
