Maximize efficiency with the SD25 Valve, an electro-hydraulic control and automation solution designed for various applications, including material handling, construction, agriculture, and industrial vehicles.
| Seri SD25 Kran Arah Bagian Parameter | |
|---|---|
| Metode Kontrol | Buku Panduan, Elektro-hidraulik, Hidraulis |
| Spul | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool |
| Kisaran Suhu Sekitar | -40°C hingga +80°C (-40°F hingga +176°F) |
| Tipe Struktur | Katup penampang |
| Bagian | 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian, 8 Bagian, 9 Bagian, 10 Bagian |
| Kisaran Viskositas Operasional | 12 - 400 mm²/dt (12 cSt hingga 400 cSt) |
| Aliran Terukur | 240 L/menit (63,4 US gpm) |
| Tekanan Maksimum | 315 bar (4600 psi) |
| Port Masuk | G1, SAE 16 |
| Port Keluar | G1-1/4, SAE 16 |
| Ukuran Port | G1, G1-1/4, SAE 12 |
The SD25 Valve is a monoblock valve with a rated flow of 240 L/min and a maximum pressure of 315 bar. It operates within an ambient temperature range of -40°C to +80°C and features a single spool. Its electro-hydraulic control system provides precise and efficient operation, making it an ideal choice for demanding hydraulic applications.
