P120 2-Spool Hydraulic Valves | Factory Wholesale & Customization

Metode Kontrol:Buku Panduan

Spul:2 Spool

Aliran Terukur:120 L/min (31,7 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G3/4

Port Keluar:G1

Ukuran Port:G3/4

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P120 Katup Arah Monoblok

Ukuran kemasan:30*39*17

Kelas kotor:19.00 kg

Ketersediaan: Tersedia

984 Pandangan Mencari Produk Ini

P120 2-Spool Hydraulic Valves | Factory Wholesale & Customization

P120 2-Spool Hydraulic Valves | Factory Wholesale & Customization

P120 2-Spool Hydraulic Valves | Factory Wholesale & Customization drawing image

The P120 2-Spool Hydraulic Valve is a robust and reliable monoblock valve designed for a wide range of applications in material handling, construction, agriculture, and industrial vehicles. It features a rated flow of 120 L/min and a maximum pressure of 250 bar, making it suitable for demanding tasks.

Seri P120 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Kabel, Stik Kontrol, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool
Aliran Terukur 120 L/min (31,7 US gpm)
Tekanan Maksimum 250 bar (3600 psi)
Port Masuk G3/4, G1, M27×2.0, SAE 14, SAE 16, 3/4 NPT, 1 NPT, M36×2
Port Keluar G1, SAE 16, 1 NPT, M36×2
Ukuran Port G3/4, G1, M27×2.0, SAE 14, SAE 16, 1 NPT, M36×2
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian
Tipe Struktur Katup monoblok
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)

This high-performance hydraulic distributor valve is part of the P120 series and is specifically designed for 2-spool operation. It offers a compact and durable design with a robust monoblock construction. The valve is manually controlled and features a rated flow of 120 L/min (31.7 US gpm) with a maximum pressure rating of 250 bar (3600 psi). Its operating viscosity range is 15 - 75 mm²/s (15 cSt to 75 cSt), ensuring reliable performance in various operating conditions. The P120 2-Spool Hydraulic Valve can withstand ambient temperatures ranging from -40°C to +80°C (-40°F to +176°F). It is widely applicable in various equipment, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, mini excavators, skid steer loaders, compact wheel loaders, and wheel loaders.
