P120 Directional Valve: Quality, Performance, Reliability

Metode Kontrol:Buku Panduan

Spul:2 Spool

Aliran Terukur:120 L/min (31,7 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G1

Port Keluar:G1

Ukuran Port:G1

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P120 Katup Arah Monoblok

Ukuran kemasan:30*39*17

Kelas kotor:19.00 kg

Ketersediaan: Tersedia

1629 Pandangan Mencari Produk Ini

P120 Directional Valve: Quality, Performance, Reliability

P120 Directional Valve: Quality, Performance, Reliability

P120 Directional Valve: Quality, Performance, Reliability drawing image

The P120 Series 5/2 Directional Control Valve is a reliable and high-performance hydraulic valve designed for a wide range of applications in material handling, construction, agriculture, and industrial vehicles. This manual control valve features a robust monoblock construction, rated flow of 120 L/min, and a maximum pressure of 250 bar, making it ideal for demanding operating conditions.

Seri P120 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Kabel, Stik Kontrol, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool
Aliran Terukur 120 L/min (31,7 US gpm)
Tekanan Maksimum 250 bar (3600 psi)
Port Masuk G3/4, G1, M27×2.0, SAE 14, SAE 16, 3/4 NPT, 1 NPT, M36×2
Port Keluar G1, SAE 16, 1 NPT, M36×2
Ukuran Port G3/4, G1, M27×2.0, SAE 14, SAE 16, 1 NPT, M36×2
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian
Tipe Struktur Katup monoblok
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)

The P120 Series 5/2 Directional Control Valve is a high-quality hydraulic valve designed for demanding applications in material handling, construction, agriculture, and industrial vehicles. This manual control valve features a robust monoblock construction, providing exceptional durability and reliability. With a rated flow of 120 L/min and a maximum pressure of 250 bar, this valve can handle high flow rates and pressures. The valve operates smoothly across a wide viscosity range (15-75 mm²/s) and can withstand temperatures from -40°C to +80°C. Its 2-section design and 2-spool configuration allow for precise control of hydraulic circuits. The valve is compatible with a wide range of applications, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, excavators, skid steer loaders, and compact wheel loaders.
