P120-G1 Monoblock Directional Valve | Precision Hydraulics

Metode Kontrol:Buku Panduan

Spul:1 Spool

Aliran Terukur:120 L/min (31,7 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G1

Port Keluar:G1

Ukuran Port:G1

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P120 Katup Arah Monoblok

Ukuran kemasan:19*35*16

Kelas kotor:13.60 kg

Ketersediaan: Tersedia

1189 Pandangan Mencari Produk Ini

P120-G1 Monoblock Directional Valve | Precision Hydraulics

P120-G1 Monoblock Directional Valve | Precision Hydraulics

P120-G1 Monoblock Directional Valve | Precision Hydraulics drawing image

The P120-G1 Monoblock Directional Valve is a compact and robust hydraulic cylinder control unit designed for use in a wide range of applications including material handling, construction, and agriculture. It features a 120 L/min flow rate, 250 bar pressure rating, and a manual control method. This unit is perfect for applications requiring precise and reliable hydraulic control.

Seri P120 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Kabel, Stik Kontrol, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool
Aliran Terukur 120 L/min (31,7 US gpm)
Tekanan Maksimum 250 bar (3600 psi)
Port Masuk G3/4, G1, M27×2.0, SAE 14, SAE 16, 3/4 NPT, 1 NPT, M36×2
Port Keluar G1, SAE 16, 1 NPT, M36×2
Ukuran Port G3/4, G1, M27×2.0, SAE 14, SAE 16, 1 NPT, M36×2
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian
Tipe Struktur Katup monoblok
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)

The P120-G1 Monoblock Directional Valve is a high-performance hydraulic cylinder control unit that offers exceptional reliability and durability. Designed for use in demanding environments, it features a robust monoblock valve construction and a 120 L/min flow rate, making it ideal for a wide range of applications. Its 250 bar pressure rating ensures it can handle heavy loads and demanding operating conditions. The manual control method provides precise and easy operation, while its compact design allows for easy integration into various systems. This unit is particularly well-suited for use in telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. Its wide operating temperature range (-40°C to +80°C) ensures it can perform reliably in a variety of climates.
