P40-G12-G38-2QTW Monoblock Valve | Manufacturer & Global Distributor

Metode Kontrol:Buku Panduan

Spul:2 Spool

Aliran Terukur:40 L/menit (10,5 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G1/2

Port Keluar:G1/2

Ukuran Port:G3/8

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P40 Katup Arah Monoblok

Ukuran kemasan:23*18*13

Kelas kotor:5.10 kg

Ketersediaan: Tersedia

1136 Pandangan Mencari Produk Ini

P40-G12-G38-2QTW Monoblock Valve | Manufacturer & Global Distributor

P40-G12-G38-2QTW Monoblock Valve | Manufacturer & Global Distributor

P40-G12-G38-2QTW Monoblock Valve | Manufacturer & Global Distributor drawing image

The P40-G12-G38-2QTW Monoblock Valve is a high-performance hydraulic joystick valve designed for construction and industrial equipment. It features a compact monoblock design, 2 sections, and a rated flow of 40 L/min. This valve is ideal for telehandlers, forklifts, cranes, stackers, and other heavy-duty applications.

Seri P40 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Selenoid dan Joystick, Manual dan Joystick, Solenoid dan Kabel
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 40 L/menit (10,5 US gpm)
Tekanan Maksimum 250 bar (3600 psi)
Port Masuk G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port Keluar G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Ukuran Port G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40-G12-G38-2QTW Monoblock Valve is a robust and reliable hydraulic valve with manual control. This 2-section valve features a compact monoblock design, making it suitable for applications where space is limited. It has a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure rating of 250 bar (3600 psi). This valve operates within a viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and can withstand ambient temperatures from -40°C to +80°C (-40°F to +176°F). With its 2 spools, this valve is suitable for controlling various hydraulic functions in construction and industrial equipment such as telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, excavators, skid steer loaders, and compact wheel loaders. It is specifically designed to meet the demanding requirements of these applications.
