P40-U34-2OT Manual Hydraulic Valve | Customizable & Private Label

Metode Kontrol:Buku Panduan

Spul:2 Spool

Aliran Terukur:40 L/menit (10,5 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:SAE 8

Port Keluar:SAE 8

Ukuran Port:SAE 8

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P40 Katup Arah Monoblok

Ukuran kemasan:23*18*13

Kelas kotor:4.80 kg

Ketersediaan: Tersedia

1024 Pandangan Mencari Produk Ini

P40-U34-2OT Manual Hydraulic Valve | Customizable & Private Label

P40-U34-2OT Manual Hydraulic Valve | Customizable & Private Label

P40-U34-2OT Manual Hydraulic Valve | Customizable & Private Label drawing image

This P40 Series Directional Control Valve is a manually operated, monoblock valve designed for heavy-duty applications in construction, material handling, agriculture, and industrial vehicles. It features a 2-section design, a rated flow of 40 L/min, and a maximum pressure of 250 bar. The valve is customizable and available with private label options.

Seri P40 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Selenoid dan Joystick, Manual dan Joystick, Solenoid dan Kabel
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 40 L/menit (10,5 US gpm)
Tekanan Maksimum 250 bar (3600 psi)
Port Masuk G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port Keluar G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Ukuran Port G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

This high-performance P40 Series Directional Control Valve is a reliable solution for various applications, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, compact wheel loaders, and wheel loaders. Its manual operation provides precise control over hydraulic circuits. The valve is engineered with a robust monoblock structure for superior durability and long service life. With a rated flow of 40 L/min and a maximum pressure of 250 bar, this valve delivers efficient performance in demanding environments. It operates within a wide viscosity range of 15-75 mm²/s (15 cSt to 75 cSt) and withstands ambient temperatures from -40°C to +80°C (-40°F to +176°F). We offer customization options to meet your specific requirements. This valve is also available for private label branding, allowing you to create a unique identity for your products.
