P40-U34 Hydraulic Valve | Reliable Performance & Custom Solutions

Metode Kontrol:Buku Panduan

Spul:1 Spool

Aliran Terukur:40 L/menit (10,5 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:SAE 8

Port Keluar:SAE 8

Ukuran Port:SAE 8

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P40 Katup Arah Monoblok

Ukuran kemasan:23*16*11

Kelas kotor:3.00 kg

Ketersediaan: Tersedia

1013 Pandangan Mencari Produk Ini

P40-U34 Hydraulic Valve | Reliable Performance & Custom Solutions

P40-U34 Hydraulic Valve | Reliable Performance & Custom Solutions

P40-U34 Hydraulic Valve | Reliable Performance & Custom Solutions drawing image

The P40-U34 Hydraulic Valve is a reliable and customizable solution for a wide range of applications, including cranes, telehandlers, and construction equipment. This manual, monoblock valve features a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure of 250 bar (3600 psi).

Seri P40 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Selenoid dan Joystick, Manual dan Joystick, Solenoid dan Kabel
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 40 L/menit (10,5 US gpm)
Tekanan Maksimum 250 bar (3600 psi)
Port Masuk G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port Keluar G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Ukuran Port G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40-U34 Hydraulic Valve is a high-performance control valve designed for demanding applications in material handling, construction and earthmoving, agriculture, and industrial vehicles. This manual, monoblock valve features a single spool and offers reliable performance with a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure of 250 bar (3600 psi). The P40-U34 is suitable for a wide range of applications, including telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, and skid steer loaders. The valve is built with high-quality materials and components, ensuring durability and long service life. With its customizability options, the P40-U34 can be tailored to meet specific requirements, ensuring optimal performance and efficiency for your application.
