P80-AQF-G Series Monoblock Directional Valve: Wholesale & OEM

Metode Kontrol:Buku Panduan

Spul:6 Spool

Aliran Terukur:80 L/menit (21,2 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G3/4

Port Keluar:G3/4

Ukuran Port:G1/2

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P80 Katup Arah Monoblok

Ukuran kemasan:26*36*11

Kelas kotor:18.60 kg

Ketersediaan: Tersedia

1055 Pandangan Mencari Produk Ini

P80-AQF-G Series Monoblock Directional Valve: Wholesale & OEM

P80-AQF-G Series Monoblock Directional Valve: Wholesale & OEM

P80-AQF-G Series Monoblock Directional Valve: Wholesale & OEM drawing image

The P80-AQF-G Series Monoblock Directional Valve is a high-performance hydraulic control valve designed for a wide range of applications, including material handling, construction, earthmoving, agriculture, and industrial vehicles. This 6-section valve features a rated flow of 80 L/min and a maximum pressure rating of 250 bar, making it ideal for demanding applications.

Seri P80 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 80 L/menit (21,2 US gpm)
Tekanan Maksimum 315 bar (4600 psi)
Port Masuk G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port Keluar G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Ukuran Port G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

This Three Way Hydraulic Control Valve, part of the P80-AQF-G series, is a robust monoblock directional valve designed for demanding applications in industries such as material handling, construction, and earthmoving. This 6-section valve boasts a rated flow of 80 L/min and a maximum pressure rating of 250 bar, ensuring high performance and reliability. Its manual control method offers user-friendly operation. With a wide operating viscosity range of 15 to 75 mm²/s and an ambient temperature range of -40°C to +80°C, this valve is suitable for diverse operating environments. Its 6-spool design provides versatility and control for various hydraulic circuits. This valve is perfect for a wide range of machinery, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. We offer wholesale and OEM options for this valve, catering to diverse needs. Contact us for more details and customized solutions.
