P80 Directional Control Valve | Factory Direct Supply

Metode Kontrol:Buku Panduan

Spul:4 Spool

Aliran Terukur:80 L/menit (21,2 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G1/2

Port Keluar:G1/2

Ukuran Port:G1/2

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P80 Katup Arah Monoblok

Ukuran kemasan:26*23*11

Kelas kotor:13.40 kg

Ketersediaan: Tersedia

1027 Pandangan Mencari Produk Ini

P80 Directional Control Valve | Factory Direct Supply

P80 Directional Control Valve | Factory Direct Supply

P80 Directional Control Valve | Factory Direct Supply drawing image

The P80 Directional Control Valve is a robust and reliable lever-operated hydraulic valve designed for a wide range of applications in material handling, construction, agriculture, and industrial vehicles. This 4-section, monoblock valve features a rated flow of 80 L/min and a maximum pressure of 250 bar, making it suitable for demanding tasks. Available directly from the manufacturer, it is perfect for wholesale orders and OEM applications.

Seri P80 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 80 L/menit (21,2 US gpm)
Tekanan Maksimum 315 bar (4600 psi)
Port Masuk G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port Keluar G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Ukuran Port G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The P80 Directional Control Valve is a high-performance hydraulic valve with a manual control method. This 4-section monoblock valve boasts a rated flow of 80 L/min and a maximum pressure of 250 bar, ensuring efficient operation in demanding applications. Designed for durability, it offers a wide operating viscosity range (15 - 75 mm²/s) and can withstand ambient temperatures from -40°C to +80°C. With its 4-spool configuration, the P80 Series is ideal for use in various equipment types, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. As a factory direct supplier, we offer competitive pricing and bulk order discounts. Contact us today to discuss your specific requirements and explore the benefits of our factory wholesale program.
