P80 Electro-hydraulic Valve: Distributors & Wholesalers Wanted Worldwide

Metode Kontrol:Elektro-hidraulik

Spul:4 Spool

Aliran Terukur:80 L/menit (21,2 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G1/2

Port Keluar:G3/4

Ukuran Port:G1/2

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P80 Katup Arah Monoblok

Ukuran kemasan:50*40*20

Kelas kotor:23.00 kg

Ketersediaan: Tersedia

555 Pandangan Mencari Produk Ini

P80 Electro-hydraulic Valve: Distributors & Wholesalers Wanted Worldwide

P80 Electro-hydraulic Valve: Distributors & Wholesalers Wanted Worldwide

P80 Electro-hydraulic Valve: Distributors & Wholesalers Wanted Worldwide drawing image

P80 Series electro-hydraulic monoblock valve, rated at 80 L/min and 315 bar, ideal for material handling, construction, and agricultural applications. We offer manufacturing, OEM, ODM, customization, and wholesale options. Distributors and wholesalers worldwide are welcome.

Seri P80 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 80 L/menit (21,2 US gpm)
Tekanan Maksimum 315 bar (4600 psi)
Port Masuk G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port Keluar G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Ukuran Port G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The P80 Series Electro-hydraulic Valve is a high-performance, 4-section monoblock valve with a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 315 bar (4600 psi). Designed for demanding applications in material handling, construction and earth moving, industrial vehicles, and agriculture, this robust valve is suitable for forklifts, skid steer loaders, compact wheel loaders, tractors, telehandlers, mini- and midi-excavators, harvesters, balers, and backhoes.

**Key Features:**
* Electro-hydraulic control for precise operation
* 4-section monoblock design for reliability and compactness
* High flow rate (80 L/min)
* High-pressure rating (315 bar)
* Wide operating viscosity range (15-75 mm²/s)
* Wide ambient temperature range (-40°C to +80°C)
* 4 spool design for versatile control

**Business Opportunities:**
As a leading manufacturer, we offer a comprehensive range of services, including manufacturing, OEM (Original Equipment Manufacturing), ODM (Original Design Manufacturing), customization, and wholesale distribution. We are actively seeking reliable distributors, wholesalers, agents, and trading companies worldwide to expand our global reach. Partner with us to tap into the growing demand for high-quality electro-hydraulic valves.

**Factory Direct Supply:**
Benefit from our factory-direct pricing and consistent product quality. We provide large-scale wholesale options to meet your business needs, guaranteeing competitive pricing and fast delivery times. Contact us today to discuss your requirements and explore a mutually beneficial partnership.

**Contact Us:** [Insert Contact Information Here]

This powerful and versatile valve offers excellent value and performance, making it an ideal choice for various applications. Become a valued partner and join us in supplying the global market with this superior hydraulic solution. We are eagerly awaiting your inquiries!
