P80-G12 Manual 1 Spool Monoblock Directional Valve | Hydraulic Supplier

Metode Kontrol:Buku Panduan

Spul:1 Spool

Aliran Terukur:80 L/menit (21,2 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G1/2

Port Keluar:G1/2

Ukuran Port:G1/2

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P80 Katup Arah Monoblok

Ukuran kemasan:26*15*11

Kelas kotor:5.00 kg

Ketersediaan: Tersedia

1186 Pandangan Mencari Produk Ini

P80-G12 Manual 1 Spool Monoblock Directional Valve | Hydraulic Supplier

P80-G12 Manual 1 Spool Monoblock Directional Valve | Hydraulic Supplier

P80-G12 Manual 1 Spool Monoblock Directional Valve | Hydraulic Supplier drawing image

The P80-G12 Manual 1 Spool Monoblock Directional Valve is a reliable and durable hydraulic component designed for use in various applications, including material handling, construction, and agriculture. This manual control valve features a single spool and a maximum pressure rating of 250 bar, making it suitable for a wide range of hydraulic systems.

Seri P80 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 80 L/menit (21,2 US gpm)
Tekanan Maksimum 315 bar (4600 psi)
Port Masuk G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port Keluar G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Ukuran Port G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The P80-G12 Manual 1 Spool Monoblock Directional Valve is a high-quality hydraulic component manufactured for global markets. This valve is designed for manual control with a single spool and a monoblock structure, offering a compact and efficient design. It has a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure rating of 250 bar (3600 psi), making it suitable for various demanding applications. The operating viscosity range is 15 - 75 mm²/s (15 cSt to 75 cSt), and it can operate in ambient temperatures ranging from -40°C to +80°C (-40°F to +176°F). This valve is specifically designed for use in various applications, including material handling, construction, and agriculture. It is compatible with a wide range of equipment, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi excavators, mini excavators, skid steer loaders, and compact wheel loaders. As a leading hydraulic product manufacturer, we offer a comprehensive range of services including manufacturing, OEM, private labeling, customization, and wholesale. We are actively seeking distributors, wholesalers, agents, and traders to expand our global reach.
