P80-G12-OW Directional Valve: Manufacturer Direct & Global Distribution

Metode Kontrol:Buku Panduan

Spul:1 Spool

Aliran Terukur:80 L/menit (21,2 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G1/2

Port Keluar:G1/2

Ukuran Port:G1/2

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P80 Katup Arah Monoblok

Ukuran kemasan:26*15*11

Kelas kotor:5.00 kg

Ketersediaan: Tersedia

972 Pandangan Mencari Produk Ini

P80-G12-OW Directional Valve: Manufacturer Direct & Global Distribution

P80-G12-OW Directional Valve: Manufacturer Direct & Global Distribution

P80-G12-OW Directional Valve: Manufacturer Direct & Global Distribution drawing image

The 62 Hydraulic Valve P80-G12-OW is a high-performance, manual directional valve designed for demanding applications in construction, material handling, agriculture, and industrial vehicles. With a rated flow of 80 L/min and a maximum pressure of 250 bar, this monoblock valve is ideal for controlling hydraulic systems in a variety of equipment, including telehandlers, forklifts, cranes, and excavators.

Seri P80 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 80 L/menit (21,2 US gpm)
Tekanan Maksimum 315 bar (4600 psi)
Port Masuk G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port Keluar G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Ukuran Port G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

This 1-section, manual directional valve features a robust monoblock construction, providing exceptional durability and reliability. With a rated flow of 80 L/min and a maximum pressure of 250 bar, it is suitable for a wide range of applications. The valve is designed for use in ambient temperatures ranging from -40°C to +80°C, making it suitable for challenging operating environments. Its compact size and ease of installation make it an ideal choice for a variety of equipment, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, and compact wheel loaders. The 62 Hydraulic Valve P80-G12-OW is a versatile and reliable solution for controlling hydraulic systems in demanding applications.
