P80-U1-J2OT Joystick 2 Spool Monoblock Directional Valve for Hydraulic Systems

Metode Kontrol:Stik Kontrol

Spul:2 Spool

Aliran Terukur:80 L/menit (21,2 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:SAE 12

Port Keluar:SAE 12

Ukuran Port:SAE 10

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P80J Katup Arah Monoblok

Ukuran kemasan:26*18*11

Kelas kotor:8.19 kg

Ketersediaan: Tersedia

77 Pandangan Mencari Produk Ini

P80-U1-J2OT Joystick 2 Spool Monoblock Directional Valve for Hydraulic Systems

P80-U1-J2OT Joystick 2 Spool Monoblock Directional Valve for Hydraulic Systems

P80-U1-J2OT Joystick 2 Spool Monoblock Directional Valve for Hydraulic Systems drawing image

The P80-U1-J2OT is a high-performance 2-spool monoblock directional control valve featuring joystick operation, designed for precision hydraulic systems with a rated flow of 80 L/min and operating pressures up to 250 bar.

Seri P80J Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Listrik, Solenoid dan Manual, Selenoid dan Joystick, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 80 L/menit (21,2 US gpm)
Tekanan Maksimum 315 bar (4600 psi)
Port Masuk G1/2, G3/4, M20×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port Keluar G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Ukuran Port G1/2, G3/4, M20×1.5, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT

As a leading manufacturer of hydraulic components, we provide the P80-U1-J2OT Joystick 2 Spool Monoblock Directional Valve, engineered for versatile applications in agriculture, construction, and material handling. This P80J series valve supports a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 250 bar (3600 psi), making it ideal for mini-excavators, skid steer loaders, and tractors. We offer comprehensive OEM, ODM, and private labeling services for global partners. Our factory specializes in large-scale production, offering competitive wholesale pricing and customization options to meet specific technical requirements. We are actively seeking distributors, wholesalers, agents, and traders to expand our global network. With SAE 12 inlet/outlet ports and SAE 10 working ports, this valve ensures reliable performance in wood splitters, forklifts, and industrial vehicles. Partner with a professional factory supplier for high-quality hydraulic solutions and stable bulk supply.
