P80F-G34 Hydraulic Control Valve is a monoblock valve designed for various applications. With a rated flow of 80 L/min and a max pressure of 250 bar, it offers reliable performance in demanding hydraulic systems.
| Seri P80F Katup Arah Monoblok Parameter | |
|---|---|
| Spul | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Metode Kontrol | Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol |
| Ukuran Port | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Bagian | 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian |
| Kisaran Suhu Sekitar | -40°C hingga +80°C (-40°F hingga +176°F) |
| Kisaran Viskositas Operasional | 15 - 75 mm²/dt (15 cSt hingga 75 cSt) |
| Port Keluar | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT |
| Tekanan Maksimum | 315 bar (4600 psi) |
| Aliran Terukur | 80 L/menit (21,2 US gpm) |
| Tipe Struktur | Katup monoblok |
| Port Masuk | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
**P80F-G34 Hydraulic Control Valve**
**Key Features:**
- Monoblock valve design for compact and efficient installation
- Rated flow of 80 L/min (21.2 US gpm) for high flow capacity
- Max pressure of 250 bar (3600 psi) for demanding applications
- Operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) for wide compatibility
- Ambient temperature range of -40°C to +80°C (-40°F to +176°F) for harsh environments
- Single spool for precise control
- Customisable and private label solutions available
**Applications:**
- Material Handling: Telehandlers, forklifts, stackers, aerial platforms
- Construction and Earth Moving: Motor graders, excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, dumpers
- Agriculture: Tractors, harvesters, sprayers
- Industrial Vehicles: Concrete boom pumps, pave rollers, rotary drilling rigs, crushers, stone cutters
The P80F-G34 Hydraulic Control Valve is an ideal choice for a wide range of hydraulic systems, providing reliable performance, customisability, and durability.
