P80F-G34-OT Manual 5 Spool Monoblock Directional Valve

Metode Kontrol:Buku Panduan

Spul:5 Spool

Aliran Terukur:80 L/menit (21,2 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G3/4

Port Keluar:G3/4

Ukuran Port:G3/4

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P80F Katup Arah Monoblok

Ukuran kemasan:26*30*11

Kelas kotor:16.00 kg

Ketersediaan: Tersedia

2063 Pandangan Mencari Produk Ini

P80F-G34-OT Manual 5 Spool Monoblock Directional Valve

P80F-G34-OT Manual 5 Spool Monoblock Directional Valve

P80F-G34-OT Manual 5 Spool Monoblock Directional Valve drawing image

The P80F-G34-OT is a robust 5-spool monoblock directional valve designed for demanding applications in construction, material handling, and industrial vehicles. It features manual control, 80 L/min flow rate, and 250 bar maximum pressure, making it ideal for controlling hydraulic systems in telehandlers, forklifts, excavators, loaders, and other heavy-duty equipment.

Seri P80F Katup Arah Monoblok Parameter
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol
Ukuran Port G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Port Keluar G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT
Tekanan Maksimum 315 bar (4600 psi)
Aliran Terukur 80 L/menit (21,2 US gpm)
Tipe Struktur Katup monoblok
Port Masuk G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT

The P80F-G34-OT is a high-performance, manual control, 5-spool monoblock directional valve specifically engineered for heavy-duty applications in construction, material handling, and industrial vehicles. This valve boasts a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure rating of 250 bar (3600 psi), ensuring efficient and reliable operation in demanding environments. The P80F-G34-OT's robust construction and versatile design make it a versatile solution for various applications, including telehandlers, forklifts, all-terrain cranes, stackers, motor graders, mini-excavators, skid steer loaders, compact wheel loaders, backhoe loaders, harvesters, and bale wrappers. The valve's operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) allows it to operate effectively in a wide range of hydraulic fluids and temperatures, from -40°C to +80°C (-40°F to +176°F). The P80F-G34-OT is a reliable and efficient hydraulic control solution designed to withstand the rigors of heavy-duty applications.
