P81 Manual 1 Spool Log Splitter Valve | Manufacturer & Global Supplier

Metode Kontrol:Buku Panduan

Spul:1 Spool

Aliran Terukur:80 L/menit (21,2 US gpm)

Tekanan Maksimum:Tekanan Maksimum

Port Masuk:G1/2

Port Keluar:G3/4

Ukuran Port:G3/4

Merek:BXHS

Tipe Produk:Katup Pembelah Kayu

Seri Produk:Seri P81 Katup Pembelah Kayu

Ukuran kemasan:27*16*12

Kelas kotor:4.80 kg

Ketersediaan: Tersedia

1871 Pandangan Mencari Produk Ini

P81 Manual 1 Spool Log Splitter Valve | Manufacturer & Global Supplier

P81 Manual 1 Spool Log Splitter Valve | Manufacturer & Global Supplier

P81 Manual 1 Spool Log Splitter Valve | Manufacturer & Global Supplier drawing image

This P81 Series Hydraulic 2 Way Valve is a manual, 1-spool, monoblock valve designed for log splitter applications. It features a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 250 bar (3600 psi). The valve is suitable for industrial vehicles and offers a kick-out setting pressure range of 70~140bar (1015-2030psi).

Seri P81 Katup Pembelah Kayu Parameter
Metode Kontrol Buku Panduan
Spul 1 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 80 L/menit (21,2 US gpm), 95 L/menit (25,1 US gpm)
Tekanan Maksimum Tekanan Maksimum
Port Masuk G1/2
Port Keluar G1/2
Ukuran Port G3/4

The Hydraulic 2 Way Valve P81 Manual 1 Spool Log Splitter Valve is a high-performance valve designed for use in log splitting equipment. It is a manual, 1-spool, monoblock valve that offers a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 250 bar (3600 psi). The valve features a kick-out setting pressure range of 70~140bar (1015-2030psi), providing reliable and efficient control of hydraulic fluid flow. Its operating viscosity range is 15 - 75 mm²/s (15 cSt to 75 cSt), and it can withstand ambient temperatures from -40°C to +80°C (-40°F to +176°F). This robust valve is ideal for industrial vehicle applications where durability and performance are critical. The P81 Series valve is designed specifically for wood splitting equipment, offering optimal performance and reliability for this demanding task.
