Produksi & Pengiriman
Waktu Produksi 15-30 Hari
1535 Pandangan Mencari Produk Ini
The BKQF34 Series multi-channel directional valve is a high-performance pneumatic control valve designed for a variety of construction and industrial applications. It offers a rated flow of 40 L/min and a maximum pressure of 1 MPa, making it ideal for use in forklifts, telehandlers, skid steer loaders, and other heavy equipment.
| Seri BKQF34 Katup Kontrol Pneumatik Parameter | |
|---|---|
| Metode Kontrol | Pneumatik |
| Spul | 1 Spool |
| Kisaran Suhu Sekitar | -40°C hingga +80°C (-40°F hingga +176°F) |
| Tipe Struktur | Katup monoblok |
| Bagian | 1 Bagian |
| Kisaran Viskositas Operasional | 12 - 400 mm²/dt (12 cSt hingga 400 cSt) |
| Aliran Terukur | 40 L/menit (10,5 US gpm) |
| Tekanan Maksimum | Tekanan Dinilai |
| Port Masuk | G1/4 |
| Port Keluar | G1/4 |
| Ukuran Port | G1/4 |
This 1-section, monoblock valve features a single spool and is designed for use in harsh environments, with an operating temperature range of -40°C to +80°C. Its compact design and reliable performance make it a popular choice for manufacturers of construction, material handling, and agricultural equipment. The BKQF34 Series is available in a variety of configurations to meet specific application requirements. It is widely used in forklifts, telehandlers, skid steer loaders, compact wheel loaders, mini-excavators, midi-excavators, tractors, front-end loaders, harvesters, balers, and sprayers.
