The QFCK-F20L is a high-quality, customizable pneumatic hydraulic directional control valve designed for use in various construction, agriculture, and industrial vehicles. With a rated flow of 140 L/min and a maximum pressure of 210 bar, this valve offers reliable performance for demanding applications.
| Seri QFCK-F20L Katup Tip Parameter | |
|---|---|
| Metode Kontrol | Pneumatik |
| Spul | 1 Spool |
| Kisaran Suhu Sekitar | -40°C hingga +80°C (-40°F hingga +176°F) |
| Tipe Struktur | Katup monoblok |
| Bagian | 1 Bagian |
| Kisaran Viskositas Operasional | 15 - 75 mm²/dt (15 cSt hingga 75 cSt) |
| Aliran Terukur | Aliran Dinilai |
| Tekanan Maksimum | 210 bar (3045 psi) |
| Port Masuk | G3/4 |
| Port Keluar | G1 |
| Ukuran Port | G3/4, G1, G1/4 |
This robust directional control valve features a monoblock construction and a single spool design. It is suitable for operating pressures up to 210 bar (3045 psi) and has a rated flow of 140 L/min (37 US gpm). The valve operates with a wide viscosity range of 15-75 mm²/s (15 cSt to 75 cSt) and can withstand ambient temperatures from -40°C to +80°C (-40°F to +176°F). Its versatility makes it ideal for use in a wide range of applications, including telehandlers, forklifts, mini and midi excavators, skid steer loaders, wheel loaders, backhoe loaders, dumpers, tractors and front-end loaders, and harvesters.
